Single Setting Torque Wrenches

SKU
5T-IW - 100T-I-SETW
Product Details
  • Factory Pre-Set models are set at the factory to the customer’s specified torque setting, and are furnished with a Certificate of Calibration
  • Please specify desired torque setting when order is placed
  • Featuring a durable, non-slip cushion grip
  • Uses universal round shank interchangeable heads
  • Audible click and feel impulse torque control mechanism
  • Tamper proof torque setting for production line use
  • Accuracy: ± 3% CW of indicated value, in direction of torque indicator, from 20% to 100% of full scale
  • Designed for use on production lines and other applications where a specific torque is required for repetitive operations
  • Tamper proof torque setting for production line use Meets or exceeds ASME B107.300-2010
Documents
Add to Wish List Send a Request
Technical Details
Grouped product items
Product Buy online
5T-IW 10-50 lbf·in 1.1-5.6 N·m 0.425 in 6.5 in 0.63 in 0.61 in 1 in 0.35 lb
5T-I-SETW 10-50 lbf·in 1.1-5.6 N·m 0.425 in 6.5 in 0.63 in 0.61 in 1 in 0.35 lb
10T-IW 50-250 lbf·in 5.6-28 N·m 0.425 in 10 in 0.63 in 0.61 in 1 in 0.55 lb
10T-I-SETW 50-250 lbf·in 5.6-28 N·m 0.425 in 10 in 0.63 in 0.61 in 1 in 0.55 lb
10ST-IW 60-300 lbf·in 6.8-34 N·m 0.425 in 6.2 in 0.68 in 0.86 in 1.4 in 0.75 lb
10ST-I-SETW 60-300 lbf·in 6.8-34 N·m 0.425 in 6.2 in 0.68 in 0.86 in 1.4 in 0.75 lb
50T-IW - lbf·in 20-102 N·m 0.425 in 11 in 0.68 in 0.96 in 1.4 in 1.4 lb 15-75 lbf·ft
50T-I-SETW 20-102 N·m 0.425 in 11 in 0.68 in 0.96 in 1.4 in 1.4 lb 15 - 75 lbf·ft
100T-IW 41-203 N·m 0.560 in 19.5 in 0.94 in 0.96 in 1.4 in 2.3 lb 30 - 150 lbf·ft
100T-I-SETW 41-203 N·m 0.560 in 19.5 in 0.94 in 0.96 in 1.4 in 2.3 lb 30 - 150 lbf·ft
200T-IW 54-271 N·m 0.560 in 23.5 in 0.94 in 0.86 in 1.4 in 2.6 lb 40-200 lbf·ft
200T-I-SETW 54-271 N·m 0.560 in 23.5 in 0.94 in 0.86 in 1.4 in 2.6 lb 40 - 200 lbf·ft
300T-IW 135-406 N·m 0.735 in 27.7 in 1.12 in 1 in 1.4 in 3.9 lb 100-300 lbf·ft
300T-I-SETW 135-406 N·m 0.735 in 27.7 in 1.12 in 1 in 1.4 in 3.9 lb 100 - 300 lbf·ft
600T-IW 162-814 N·m 0.990 in 55 in 1.5 in 1.25 in 1.25 in 10.45 lb 120-600 lbf·ft
600T-I-SETW 162-814 N·m 0.990 in 55 in 1.5 in 1.25 in 1.25 in 10.45 lb 120-600 lbf·ft
